Produkt video anmeldelse
Tablet styrer robotkamera
Tabletten styrer robotten, der er fremstillet helt af metal, mens den bevæger sig frit ned i kloakken for at undersøge, og det 360-graders roterende kamera overvåger, hvad der sker inde i rørene, fra en blindgydevinkel.
360 graders roterende kamera
Kameraet kan drejes 360 grader vandret, eller højden på det 180 mm kameraløftebeslag kan justeres lodret til den rigtige position.
8 justerbare lys med høj lysstyrke
Foran er der 4 stk. 7W højlysstyrke-LED'er og 2 stk. 3W ekstra-LED'er, alle med justerbar lysstyrke. 2 ikke-justerbare LED-lys bagpå. Det kan hjælpe dig med at skifte mellem situationer før og efter inspektionen uden pres.
Fuld metalhus IP68 vandtæt
Fuld metalkabinet, IP68 vandtæt, intet tryk i slam, pool, sivebrønd og andre barske miljøer. Den kan rengøres med en vandpistol direkte efter brug.
4-hjulstræk med to motorer
Motoren anvender dobbeltmotorisk firehjulstræk, anvender 2*50W højeffektiv DC børsteløs motor, og den kravlende robots kørehastighed kan justeres i tre gear.
Tilpasning til forskellige scenarier
Afhængigt af de forskellige forhold i rørledningen er den maksimale klatrekapacitet ikke mindre end 30°, og den kan bevæge sig frit i slammet. Ved at anvende et specielt kabel til rørledningsrobotten kan kroppen bære 50 kg.
Automatisk slip og rul spolen op
Bakspejlhovedet bruges til bæltemaskiner til at observere bakning og kabeloprulning mellem færdiggørelsesopgaver. Automatisk udløsning og oprulning af spolen gør arbejdet lettere og mere bekvemt.
Tablet visuel målertælling
Tablet-eksklusiv APP, udover at styre krybemaskinen, kan også tage skærmbilleder, video, vise dato og klokkeslæt, byggeoplysninger, beregne længden af kabeludløseren og andre oplysninger.
2M High Definition billedkvalitet
Du kan frit navigere gennem mudrede rør og optage i 2MP HD-kvalitet for at få et stressfrit kig på, hvad der foregår indeni.
360 graders roterende robotkamera
- Helmetalhus IP68 vandtæt
- 2M HD-kamera billedkvalitet
- Tablet PC WIFI-kontrolboks til visning af forhold i realtid
|
Specifications
|
||
| Robot Camera | Material | High Strength Alloy Material |
| Motoring | Mode Four-wheel Motoring | |
| Moving Mode | Four-wheel Crawling | |
| Speed | 2-25 meters/min Three adjustable speeds |
|
| Motor Power | 100W | |
| Camera Pixel | 2 Megapixel | |
| Lens Rotation Angle | Infinite 360-degree uniform rotation | |
| Lens Flip Angle | 190 Degrees | |
| The Lens Material | Alloy Steel | |
| Light Power | 40W | |
| Front Camera Lighting Source | 4 primary camera lights, 2 secondary camera lights |
|
| Backward Camera Light Source | 2 camera lights | |
| Waterproof | IP68 | |
| Size | 522.5mm*212mm*198.5mm/ 20.5in*8.35in*7.8in |
|
| Weight | 9.8KG | |
Pakkeliste
Robotkamera *1
Metalrammespoler *1
Tablet-pc *1
Strømkabel *1
Customers praised the robotic sewer crawler's 360-degree rotating camera for effective pipeline inspection. "Very well built and easy to operate," with "outstanding" full-metal body and IP68 waterproof rating. Shoppers noted excellent durability for tough environments and praised professional customer service.
Camera (positive)Quality (positive)Inspection (positive)Durability (positive)Service (positive)
R
when I received the crawler robot camera and opened the package, found it very textured and has many functions. I will leave my experience after using it.
R
Yes, everything appears to working as intended now. We were able to use the robot for the scheduled work and had no issues.
Thank you Lisa, I very much appreciate your prompt responses and professionalism.
A
i posted a review yesterday 6/22/26 about not getting the display screen with the original package it was sent to our po box some how i received it today and was able to put the system to work right a way and was vary impressed. very well built and easy to operate would recommend this product to anyone been bragging about it all day.
A
Vary good product
O
The build quality is outstanding full-metal body with IP68 waterproof rating means I could literally hose it down after use within sludge-filled drains. Highly durable for tough environments.
P
I recently used the crawler robot and I’m really impressed with the 360-degree rotating camera. it gives a clear pipeline, which makes inspection so much more effective.
A
Does unit use a rechargeable battery pack or does unit need to be plugged in. Can distant switched between meters and ft? Can I order both sets of tires if so what is the price for both tire sizes .
Hello,Antoine.
Thank you for your questions about the SANYIPACE U99360.
Power Supply: The U99360 crawler system does not run from a rechargeable battery pack. It requires a 110–220V AC power source and comes with a power cable. If you are working where AC power is not available, a suitable external inverter power supply can also be used.
Distance Counter: The built-in distance counter displays the cable distance in meters. Please note that the distance unit is preset at the factory and cannot be switched or converted between meters and feet through the settings.
Tire Sizes: The crawler is available with 150 mm or 220 mm tires. You can have both sizes. When ordering the complete U99360, you can select one tire size with the unit and purchase the other size separately. The additional tire set is currently $500.99.
If you would like, we can also help you choose between the 150 mm and 220 mm tires based on the pipe diameters you normally inspect.
S
What size pipe is this designed for
HI Scott,I’m glad to assist you. This model measures 20.5in*8.35in*7.8in and is suitable for pipes that are at least 10 inches in size.
M
Does it have GPS or 512 Mhz transmitir? Whats longest línea available ?
Hi Manuel. Our current U99360 robot does not come equipped with a 512Hz transmitter, but you could purchase one and attach it to the robot for use with a 512Hz locator ( The 512Hz locator can receive signals when the 512Hz transmitter is within 5 meters/16.4ft deep). The longest coil supported by the U99360 robot is 120M/393ft. If you have any further questions, please feel free to contact us.
512Hz transmitter & locator purchase link： https://sanyipace.com/collections/sewer-camera/products/512hz-sewer-camera-locator-underground-drain-locator-s68r?variant=46120677638361
Customer Service Email: service@sanyipace.com
J
Bonjour
est ce que le robot donne les inclinaisons de pente
et à partir de quel diamètre de conduit on peu l 'utiliser
cordialement
Philippe jouffret
Bonjour JOUFFRET, nous avons le regret de vous informer que le robot U99360 ne peut pas mesurer et afficher les données d'angle. Mais il peut gravir une pente de 30 degrés. Et le robot U99360 peut passer sans difficulté dans des tuyaux d'un diamètre supérieur à 11,81 pouces/300 mm.
R
What’s the smallest pipe it can crawl through?
Dear Customer. The smallest pipe it can crawl through is 300mm/11.81 inches. For pipes wider than 300mm/11.81 inches but narrower than 700mm/27.56 inches, straight passages are permitted, but turning is not allowed. Passages wider than 700mm are permitted to turn.
